防火電纜橋架廠家的劃線定位

Marking and positioning of fire-resistant cable tray manufacturers

當蓋板掩蓋時，線槽接口應與插槽蓋接口移位，防止兩個接口堆疊，然后可以進步整個線槽的剛性。缺少陽角關節(jié)時的施工方法。剛性角接頭用于線槽作為90°彎曲的線槽。在制作時，插槽側高度尺度高度尺度，在一條線槽的結束底部，并且用切開切出DIPK。在另一條線槽端，每次切開沿凹槽的底表面和兩個槽的周圍面的刀，切開深度是凹槽側的高尺度，然后切開彎曲槽的底部，然后彎曲部分聯接到前部槽口用鉚釘固定。相應的槽蓋彎曲，并且可以發(fā)現線槽由90°彎曲制成。

When the cover plate is covered, the slot interface should be shifted from the slot cover interface to prevent the two interfaces from stacking, and then the rigidity of the entire slot can be improved. The construction method when there is a lack of male corner joints. Rigid corner joints are used for trunking as 90 ° curved trunking. During production, the height scale of the slot side is at the bottom of the end of a wire slot, and DIPK is cut out by cutting. At the other end of the wire groove, cut the bottom surface of the groove and the surrounding surfaces of both grooves with a knife each time, with a cutting depth of the high scale of the groove side. Then cut the bottom of the curved groove, and the curved part is connected to the front slot and fixed with rivets. The corresponding slot cover is bent, and it can be observed that the cable tray is made of a 90 ° bend.

聯接聯接頭時的施工方法。內部（外部）聯接頭附件是在相同規(guī)格線之間運用封閉。當結構可以選用約15-20厘米的相同尺度的截面，而不是聯接頭部成品?！奥摻悠鳌币话闱度刖€槽（內聯接器）的內部，以堅持整個線路槽的外觀。將“關節(jié)”鉆頭更好，用自攻螺釘或芯鋁釘固定“聯接器”。

Construction methods for connecting joints. Internal (external) connector accessories are enclosed between lines of the same specification. When the structure can be selected with a cross-section of about 15-20 centimeters of the same scale, instead of connecting the head products. The "coupler" is generally embedded inside the conduit (inline connector) to maintain the appearance of the entire conduit. Better use a "joint" drill bit and secure the "coupler" with self tapping screws or core aluminum nails.

電纜橋架時的施工方法。當線槽在90°內彎曲時運用曲線角接頭，這可以通過切開罐自身來抵達意圖。這種做法如下：在線槽的雙面槽側，它在內彎的周圍面上交叉。運用鐵切成兩個45°的空隙，然后線槽減小到空隙，使得凹槽的周圍面向外，然后鉚接固定固定，以便制作簡單，凹槽相應部分的蓋可以彎曲，并且可以在蓋子的兩頭切開兩頭，并且可以制作槽蓋。

Construction methods for cable trays. When the trunking bends within 90 degrees, use curved corner joints, which can be achieved by cutting open the can itself. This approach is as follows: on the double-sided groove side of the online slot, it intersects on the surrounding surface of the inner bend. Cut iron into two 45 ° gaps, then reduce the wire groove to the gap so that the groove faces outward, and then rivet and fix it for easy production. The cover of the corresponding part of the groove can be bent, and both ends of the cover can be cut open, and the groove cover can be made.
